Product name Kokowall® Standard acoustic barrier
Absorbent / reflective Sound absorbent
Dimensions (w x h) 3960 x 2000




The Kokowall® Standard acoustic barrier has a steel frame and cassettes with an outer layer of durable coconut fibre which allows various types of climbing plants to grow on them. A Kokowall® screen is fully overgrown within a few years.

Applications

Residential areas, industrial estates, municipal roads, motorways and railway lines.

Key features

  • Natural, ecological and attractive
  • High sound insulation and sound absorption
  • Available in any lower height and smaller widths
  • Climbing plants can grow on both sides
  • Cost-effective
  • Certification: CE in accordance with EN14388: 2005 and GCW2012
  • Certificate: NL Green label A and European patented
  • Relatively short construction time

Technical properties

  • Sound absorption EN1793-1: Dla = 7dB (a) cat. A2
  • Sound insulation EN1793-2: Rw=30dB (a) Dlr=27dB (a) cat. B3
  • Optional: higher sound insulation Dlr rail >30 dB (a)
  • Maximum construction height: 10m (through stacked panels)
  • Panel weight: 22-28kg/m2
  • Standard panel width: 3960mm (max 4960mm)
  • Maximum panel height: 2000mm (with W=3960mm)
  • Panel thickness: 9cm
  • Foundation: vibratory-driven foundation pile, onto which a lintel is mounted
  • Steel frame and posts version: galvanised or powder coated


The Kokowall® Standard acoustic barrier has a steel frame and cassettes with an outer layer of durable coconut fibre which allows various types of climbing plants to grow on them. A Kokowall® screen is fully overgrown within a few years.

Applications

Residential areas, industrial estates, municipal roads, motorways and railway lines.

Key features

  • Natural, ecological and attractive
  • High sound insulation and sound absorption
  • Available in any lower height and smaller widths
  • Climbing plants can grow on both sides
  • Cost-effective
  • Certification: CE in accordance with EN14388: 2005 and GCW2012
  • Certificate: NL Green label A and European patented
  • Relatively short construction time

Technical properties

  • Sound absorption EN1793-1: Dla = 7dB (a) cat. A2
  • Sound insulation EN1793-2: Rw=30dB (a) Dlr=27dB (a) cat. B3
  • Optional: higher sound insulation Dlr rail >30 dB (a)
  • Maximum construction height: 10m (through stacked panels)
  • Panel weight: 22-28kg/m2
  • Standard panel width: 3960mm (max 4960mm)
  • Maximum panel height: 2000mm (with W=3960mm)
  • Panel thickness: 9cm
  • Foundation: vibratory-driven foundation pile, onto which a lintel is mounted
  • Steel frame and posts version: galvanised or powder coated
