Functions Filtration
Separation
Material Polypropylene
Type Needle punched
Non woven
Roll dimensions (w x l) 4.5 x 100
Weight (g/m2) 200
Tensile strength (kN/m) 18
Elongation at maximum load (%) 50
Static puncture resistance (N) 2900
Cone drop penetration (mm) 18
Water permeability (m/sec) 80 x 10-3



Lotrak® 200 is a mechanically bonded needle-punched non-woven geotextile which has the ability to withstand a variety of larger granular materials, whilst retaining an effective filtration capability.

Lotrak® 200 is also an ideal filtration geotextile when used in conjunction with an installed crate infiltration Sustainable Urban Drainage System (SuDS). The main purpose of this geotextile is to offer higher mechanical strength in separation and filtration applications.

Lotrak® 200 is approved by Network Rail (Certificate of Acceptance PA05/06066) for drainage applications such as pipe or trench wrap and conforms to NR/SP/TRK/010 ‘Geotextiles’. (PADS Number: 057/101450)

Benefits

  • Proven separator performance
  • Effective filtration capabilities

Main applications

  • Sustainable Urban Drainage Systems (SuDS)
  • French drains
  • Narrow trench drains
