Heald’s Mantis range is a static security bollard system made from hot dip galvanised steel, designed for high-impact vehicle mitigation with shallow foundation depths of 250–300mm. Crash-tested as single units and in arrays to PAS 68 and IWA-14-1 standards at 64kph and 80kph, they combine high security with rapid installation and a choice of stainless steel covers.

  • Static security bollard system for vehicle impact protection with shallow foundations

  • Crash-tested to PAS 68 and IWA-14-1 standards at 64 and 80kph

  • Hot dip galvanised steel base for corrosion resistance

  • Zero penetration and zero dispersion in crash tests

  • Installation in under an hour with no pre-cast pit or additional rebar

  • Stainless steel covers in standard or bespoke designs and colours

  • Compatible for use in flexible arrays with other security products

Applications

  • Perimeter security for commercial and public buildings

  • Urban streetscapes requiring discreet vehicle mitigation

  • Sites with modern architectural requirements

  • Critical infrastructure protection

  • Entrances to pedestrian zones

  • Transport hubs and event venues

Dimensions

Height: 1080–1100mm (excluding cover) | 1130mm (including standard cover)

Width: 190mm (excluding cover) | 196mm (including standard cover)

Foundation depth: 250–300mm

Performance

PAS 68:2013 Fixed Bollard V/7500[N2]/64/90:0.0/0.0

IWA14-1-V/7200[N3C]/80/90:7.5 (single bollard)

IWA14-1:2013 Bollard V/7200[N2A]/80/90:3.5 (array of 3)

Zero penetration and zero dispersion in crash tests

Bollards remain protective after impact

Materials

Hot dip galvanised steel

Stainless steel covers

Colours

Can be painted any colour

Finish

Galvanised, primed and painted

Options and variations

Standard and bespoke stainless steel cover designs

Available as single units or in arrays

Installation

Excavation depth: 250–300mm

No pre-cast pit or additional rebar required

Installation in under an hour

Accreditations

PAS 68 tested

IWA-14-1 tested
