Bodpave 40 Permeable Paving Grid System is a lightweight ground reinforcement grid made from 100% recycled polymers, designed for pedestrian and light vehicle areas where drainage and surface stability are required. Each grid interlocks for secure installation and supports high load-bearing when filled with grass or gravel.

  • Lightweight, permeable paving grid for ground reinforcement

  • Supports up to 250 tonnes per square metre when filled

  • Interlocking design with snap-fit connections and ground spikes for stability

  • 95% open cell structure for effective drainage and SuDS compliance

  • Quick installation with 4 pre-connected grids covering 1m²

  • UV and weather-resistant for long-term outdoor use

  • Made from 100% recycled and recyclable polymers

  • Manufactured in the UK

Applications

  • Driveways

  • Walkways

  • Overflow car parks

  • Grass or gravel surfaces

  • Light vehicle access routes

Dimensions

500mm x 500mm x 40mm per grid

Installation

Interlocking grids with overlapping loop and snap-fit connections; integrated ground spikes

Manufacture

Made in the UK

Sustainability

Made from 100% recycled and recyclable materials
