Format Pavers
Functions Gravel stabilisation
Soil reinforcement
Turf reinforcement
Suitability Car parks
Caravan parks
Cycle routes
Driveways
Equestrian areas
Fire access routes
Footpaths
Hardstandings
Temporary car parks
Verges
Material Recycled plastic
Characteristics Recycled materials
Dimensions (l x w x d) 500x500x23
Weight (kg/m2) 6.4




CellPave™ GP from Groundtrax is a cellular grass paver system that is durable, easy to lay and made from 100% recycled materials. Offering an 85% void for water permeation, CellPave™ GP grids feature a 'spring like' flexibility, both horizontally and vertically. It can be laid on top of any grassed area and, once connected together, can be driven over immediately. Alternatively, it can be backfilled with sand, soil or decorative stone finishes.

CellPave™ GP is suitable for both permanent and temporary installations, including sloping and undulating surfaces. It improves vehicle traction and prevents surface rutting. After two to three months of grass growing, CellPave™ GP grids are virtually invisible.

Materials

CellPave™ GP is made from 100% recycled material

Size and weight

  • Tile size: 500 x 500 x 23mm (+/- 2%)
  • Size on pallet: 1000 x 1000mm (2 x 2 tiles)
  • Pallet size: 1000 x 1000 x 1600mm (contains 300 tiles / 75 layers / 75m2)
  • Weight: 6.4kg/m2 / 1.6kg per tile

Applications

  • Construction and civil engineering
  • Utilities and infrastructure access
  • Emergency access routes
  • Landscaping and groundworks
  • Outdoor events and festivals
  • Winter weather surfaces
  • Temporary roadways and car parks
  • Heritage sites, national parks and gardens
  • Golf courses and sportsfields
  • Sport and leisure facilities
  • Cemeteries
  • Overspill car parks
  • Drives, paths and cycle routes
  • Grassed areas used occasionally as vehicle or pedestrian areas
  • SUDs compliant

Key benefits

  • Fixing solutions available or can be overlaid on existing grassed surfaces
  • Protects property and grounds from damage
  • Supports heavy traffic on firm ground
  • Improves traction
  • Provides secure access for vehicles and pedestrians over soft ground
  • Avoids the need for expensive aluminium or heavy-duty systems and groundworks
  • Resists deformation and fracture
  • Rot-proof, water resistant and tough – a better and more sustainable option than wood
  • Simple to transport, carry, lay and store
  • Moulds to irregular surfaces and gradients
  • Made from 100% recycled materials and 100% recyclable after use


CellPave™ GP from Groundtrax is a cellular grass paver system that is durable, easy to lay and made from 100% recycled materials. Offering an 85% void for water permeation, CellPave™ GP grids feature a 'spring like' flexibility, both horizontally and vertically. It can be laid on top of any grassed area and, once connected together, can be driven over immediately. Alternatively, it can be backfilled with sand, soil or decorative stone finishes.

CellPave™ GP is suitable for both permanent and temporary installations, including sloping and undulating surfaces. It improves vehicle traction and prevents surface rutting. After two to three months of grass growing, CellPave™ GP grids are virtually invisible.

Materials

CellPave™ GP is made from 100% recycled material

Size and weight

  • Tile size: 500 x 500 x 23mm (+/- 2%)
  • Size on pallet: 1000 x 1000mm (2 x 2 tiles)
  • Pallet size: 1000 x 1000 x 1600mm (contains 300 tiles / 75 layers / 75m2)
  • Weight: 6.4kg/m2 / 1.6kg per tile

Applications

  • Construction and civil engineering
  • Utilities and infrastructure access
  • Emergency access routes
  • Landscaping and groundworks
  • Outdoor events and festivals
  • Winter weather surfaces
  • Temporary roadways and car parks
  • Heritage sites, national parks and gardens
  • Golf courses and sportsfields
  • Sport and leisure facilities
  • Cemeteries
  • Overspill car parks
  • Drives, paths and cycle routes
  • Grassed areas used occasionally as vehicle or pedestrian areas
  • SUDs compliant

Key benefits

  • Fixing solutions available or can be overlaid on existing grassed surfaces
  • Protects property and grounds from damage
  • Supports heavy traffic on firm ground
  • Improves traction
  • Provides secure access for vehicles and pedestrians over soft ground
  • Avoids the need for expensive aluminium or heavy-duty systems and groundworks
  • Resists deformation and fracture
  • Rot-proof, water resistant and tough – a better and more sustainable option than wood
  • Simple to transport, carry, lay and store
  • Moulds to irregular surfaces and gradients
  • Made from 100% recycled materials and 100% recyclable after use
