PAS 68 Terra V is a pair of bi-parting hinged steel security gates designed to stop a 7.5t vehicle at 50mph, with zero site penetration and full post-impact functionality. Made for perimeter protection, gates can be manual or automated, with shallow foundation requirements and a range of infill and finish options. Heights up to 5000mm and widths up to 7000mm are available.

  • Bi-parting hinged security gates for hostile vehicle mitigation

  • Impact tested to PAS 68: 7.5t at 50mph, zero penetration

  • Manual or automated operation with compatible actuators

  • Shallow foundation depth of 340mm for manual gates

  • Range of infill options including high security mesh

  • Fully functional after impact, PSSA Verified

  • Compatible with access control systems

Applications

  • Critical infrastructure protection

  • Government and military sites

  • Airports and transport hubs

  • Commercial and industrial premises

  • Data centres

  • Event security perimeters

Dimensions

Maximum width 7000mm

Standard height 2400mm

Variable heights up to 5000mm

PAS 68 tested width 4500mm

PAS 68 tested height 3000mm

Performance

PAS 68: 7.5t at 50mph (1852kJ), zero penetration

Normal operating speed 6–15 seconds

100% duty cycle

Materials

Made from fully welded steel sections

Finish

Shotblasted, hot zinc sprayed (galvanised), primed, polyurethane paint

Options and variations

Manual or automatic operation

Accumulator, manual hand pump, high security cabinet, anti-tamper alarms

Various infill types including vertical bar and 358 mesh

Installation

Shallow foundation depth 340mm for manual gates

Automatic gate foundation depends on actuator

Accreditations

PAS 68

PSSA Verified

Secured by Design

BRE Global
