AUTOPA One Way Flow Plate is a traffic control device made from galvanised heavy duty steel, designed to allow vehicles to travel in one direction only. Flap mechanism operates as vehicles pass, returning upright after use.

  • Traffic flow plate for one-way vehicle control

  • Made from galvanised heavy duty steel for durability

  • Flap returns upright after vehicle passes

  • Heavy duty rubber buffer reduces noise

  • Painted top plates for visibility

  • Ragged design for casting into concrete

  • Recommended minimum vehicle clearance of 150mm

Applications

  • Car parks

  • Private roads

  • Commercial premises

  • Access control points

Specifications

  • Body: 300 (w) x 200 (l) x 213mm (h)

  • Flap and top of heavy-duty steel plate: 12.5mm thick

  • Flap closed: 13mm above ground

  • Flap open: 133mm above ground

  • Below ground: 200mm

  • Heavy-duty hinge diameter: 19mm

  • Weight: 15kg

Materials

Heavy duty steel

Finish

Galvanised steel with painted top plates

Installation

Ragged for casting in only.

A three metre wide road would typically require 6 One Way Flow Plates.

Recommended for use with speed ramps and warning signs.

Performance

Not suitable for HGV use

Additional information

Recommended for use with speed ramps and warning signs

Recommended minimum vehicle clearance: 150mm
