FASERFIX TRAFFIC TRAM is a drainage channel made for tram tracks and rails. Four nominal widths: NW100, NW150, NW200, NW300. Handles high loads up to F900. Each 4m section drains 220l with a 552cm2 cross-section. 1m and 4m sections support flexible installation. Casing colour and surface structure can be project-matched.

  • Drainage system for tram tracks and adjacent surfaces

  • Four nominal widths: NW100, NW150, NW200, NW300

  • Handles load classes up to F900 for heavy-duty use

  • High hydraulic efficiency: 220l per 4m element

  • Section lengths: 1m and 4m for fast, flexible installation

  • Casing colour and surface structure can be matched to project needs

Applications

  • Tram tracks, rails and surrounding areas

Dimensions

  • Nominal widths: 100mm, 150mm, 200mm, 300mm

  • Section lengths: 1m, 4m

  • Cross-sectional area: 552cm2

Performance

  • Hydraulic capacity: 220l per 4m section

  • Load class: up to F900

Options and variations

  • Casing colour and surface structure can be customised
