ACO CVLR TrackDrain is a stainless steel drainage channel designed for surface and under-rail water management on 41GPU Very Light Rail tracks. Made from 10mm stainless steel, it includes a central 110mm outlet pipe and does not require mechanical fasteners or rail drilling, supporting faster installation and easy maintenance.

  • Stainless steel drainage channel for 41GPU Very Light Rail tracks

  • 10mm wall thickness for structural strength

  • Central 110mm outlet pipe for efficient water removal

  • No mechanical fasteners or rail drilling needed

  • Bolted grates allow easy access for inspection and cleaning

  • Tested to E 600 Load Class (BS EN 1433) for heavy-duty use

  • Internal arched supports withstand static loads up to 600kN

Applications

  • Very Light Rail systems

  • 41GPU rail track drainage

  • Surface and under-rail water management

  • Urban rail infrastructure projects

Dimensions

Wall thickness 10mm

Outlet pipe diameter 110mm

Materials

Stainless steel

Performance

Static load tested to 600kN

Certified to E600 Load Class (BS EN 1433)

Installation

No mechanical fasteners or rail drilling required

Maintenance

Accessible bolted grates for inspection and cleaning
