Miti-Gate®R Manual Crash Tested Vehicle Security Barrier by Cova Security Gates is a manual swing gate designed to protect against small, medium, and large vehicle threats.

Independently tested to IWA14-1:2013, CPNI Vehicle Attack Delay Standards (VADS), and PAS68:2010, it uses a patented arrestor system and can span up to 8 metres with a single leaf.

  • Manual swing barrier for vehicle security, tested to major international standards

  • Patented arrestor system housed in aluminium/steel leaf

  • Single leaf spans up to 8 metres between crash-rated bollards

  • Removable leaf in under 5 minutes

  • Shallow foundation depth of 215mm

  • Large flat surface suitable for advertising or custom graphics

  • Retrofit option for existing Miti-Gate installations

  • Manufactured in the UK

Applications

  • Public areas and high streets

  • Airports

  • Sports stadiums

  • Rail stations

  • Government buildings

  • Traffic flow management at venues

Dimensions

  • Maximum width: 8000mm

  • Nominal height: 1100mm from FFL

Performance

  • CPNI VADS 10-2019 rating: Small Vehicle Class M1B, Medium Vehicle 4x4 Class N1G

  • IWA14-1:2013: Small Vehicle Class M1B, 30mph/48kph V/1500[M1]/48/90:0.4

  • PAS68:2010: Large Vehicle Class N2, 7.5 tonne, 40mph/64kph D/7500[N2]/64/90:3.0/0.0 (design assessment)

Materials

Aluminium/steel leaf

Colours

Any RAL colour

Finish

  • Shot blasted to SA 2.5

  • Primed: galvanised or zinc primer

  • PPC topcoat to any RAL

Manufacture

Made in the UK
