Jakob Webnet Wire Mesh System is a high-strength mesh made from 316 stainless steel wire rope, designed for architectural and safety applications where transparency and durability are important. Mesh is custom-made to project dimensions and can be supplied with or without sleeves for different visual and structural needs.

  • High-strength stainless steel mesh for architectural and safety use

  • Made from marine grade 316 or 316L stainless steel

  • Custom-fabricated to project-specific sizes and shapes

  • Black anodised or powder coated finishes

  • UV and weather resistant for outdoor and indoor use

  • Minimal maintenance required

  • Certified by German Institute for Building Technology (DIBt)

Applications

  • Balustrade infill

  • Animal enclosures and zoo applications

  • Safety and fall-prevention nets

  • Green wall systems

  • Bridge and car park protection

  • Railing infill and barricades

Materials

316 and 316L stainless steel (AISI 316, 1.4401 and AISI 316L, 1.4404)

Finish

Black anodised or powder coated

Options and variations

  • With or without sleeves

  • Wide range of mesh sizes and shapes

Webnet with Sleeves

The standard Webnet specification has alternating sleeves within the web structure, making it versatile, flexible and economical – especially with small rope diameters.

Webnet without Sleeves

When specified without sleeves, Webnet is even more transparent – while delivering practically identical strength values. Because of this, sleeveless Webnet is used where strong and unobtrusive protective nets are required.

Performance

  • UV and weather resistant

  • High tensile strength

  • Minimal maintenance

Installation

Mesh is pre-fabricated to size.

Mesh is installed by threading rope through mesh edge and tensioning around structure.

Installation requires minimal tools.

Manufacture

Made in Jakob’s own manufacturing plant.

Hand-assembled and mechanically pressed for consistent quality.

Product accreditations

Certified by German Institute for Building Technology (DIBt) Z-14.7-557.
