Product name HydroPlanter™
System type Cellular
Functions Stormwater storage
Capacity (m3) 0.8 to 1.12 per module




HydroPlanter™ is a modular, 'plug and play’ bio-retention raingarden system designed to provide sustainable urban drainage solutions. It can be retrofitted into highways schemes or installed on new developments of any size.

HydroPlanter™ can attenuate and cleanse stormwater whilst providing an amenity and biodiversity to new and existing spaces. The modules will be filled with a particular soil specification, planted wildflowers and biodiverse grasses.

HydroPlanter™ is flexible and scalable, with installation being fast and simple. Individual units can be stacked together to form the required solution, and the pre-calculated hydrological peformance statistics of the modules mean that specification and design is very straightforward for any given catchment area.

HydroPlanter™ works as a fully lined system not allowing infiltration, so no further lining of the excavation is necessary. If infiltration is required, GreenBlue Urban can provide adapted HydroPlanters to suit.

Key features

  • 100% recycled materials
  • Slot-together planter modules
  • Optional exceedance flow drain point
  • Stackable design for transport efficiency

Key benefits

  • Stormwater attenuation storage
  • Excellent amenity and biodiversity values
  • Installation speed and simplicity
  • Ease of specification and design
  • Cost effectiveness
  • Freeze/thaw-resistant system

Capacities

  • HydroPlanter Starter Module (GBUHPSM1A) – 0.8m3
  • HydroPlanter Continuation Module (GBUHPCM1A) – 0.8m3
  • HydroPlanter End Module (GBUHPEM1A) – 1.12m3
  • HydroPlanter Indivdual Module (GBUHPIM1A) – 1.12m3

Materials

Modules are manufactured in the UK from 100% recycled material that can be filled with a soil specification, and planted with wildflowers and biodiverse grasses.

Delivery

Large stocks are held in the UK for immediate despatch.


HydroPlanter™ is a modular, 'plug and play’ bio-retention raingarden system designed to provide sustainable urban drainage solutions. It can be retrofitted into highways schemes or installed on new developments of any size.

HydroPlanter™ can attenuate and cleanse stormwater whilst providing an amenity and biodiversity to new and existing spaces. The modules will be filled with a particular soil specification, planted wildflowers and biodiverse grasses.

HydroPlanter™ is flexible and scalable, with installation being fast and simple. Individual units can be stacked together to form the required solution, and the pre-calculated hydrological peformance statistics of the modules mean that specification and design is very straightforward for any given catchment area.

HydroPlanter™ works as a fully lined system not allowing infiltration, so no further lining of the excavation is necessary. If infiltration is required, GreenBlue Urban can provide adapted HydroPlanters to suit.

Key features

  • 100% recycled materials
  • Slot-together planter modules
  • Optional exceedance flow drain point
  • Stackable design for transport efficiency

Key benefits

  • Stormwater attenuation storage
  • Excellent amenity and biodiversity values
  • Installation speed and simplicity
  • Ease of specification and design
  • Cost effectiveness
  • Freeze/thaw-resistant system

Capacities

  • HydroPlanter Starter Module (GBUHPSM1A) – 0.8m3
  • HydroPlanter Continuation Module (GBUHPCM1A) – 0.8m3
  • HydroPlanter End Module (GBUHPEM1A) – 1.12m3
  • HydroPlanter Indivdual Module (GBUHPIM1A) – 1.12m3

Materials

Modules are manufactured in the UK from 100% recycled material that can be filled with a soil specification, and planted with wildflowers and biodiverse grasses.

Delivery

Large stocks are held in the UK for immediate despatch.
