The School-light handrail light is a spotlight which is recessed into custom-made stainless steel handrail.

Applications

  • Handrails
  • Cycle paths
  • Pedestrian paths
  • Roadways

Specification

  • IP67 rated
  • Standard flux: 518 lm
  • Mounting type
    - wall recessed
    - handrails
  • Weight: 300 grams
  • Wide choice of lenses available
  • Very extensive asymmetric versions ensure beam uniformity with intervals of up to 7m
  • Tilted beam for tilted output even when installed vertically to hide the light source

Materials

  • Colourless anodised machined aluminium
  • Vandal-proof organic glass window
  • Flush-recessed
  • 316L stainless steel handrail available on request (Ø48 or 76mm); other sizes can be made-to-measure

Options of luminous effects

  • RGBW
  • 20° deflected beam (optional)
  • Non-adjustable
  • Beam with various openings
  • Transparent flat window
  • Colour control system (optional)

Power supply

0.2m cable length

Integrated
24V-PWM

Remote
24V-0/10V , 24V-DMX , 24V-DALI

Mechanical strength – waterproofness

  • Resists impacts up to 20 joules (IK10)
  • IP67 tight for temporary immersion

This high-quality handrail light was installed at the prestigious regeneration project at Piece Hall, Halifax.
