Terra Ultimate 180° from Frontier Pitts is a manually-operated, bi-directional hostile vehicle mitigation (HVM) hinged steel gate, impact-tested to IWA 14-1, stopping a 7.2t vehicle at 50mph, with a maximum width of 4500mm and standard height of 2400mm, suitable for locations with limited power supply.

  • Manual swing HVM gate for vehicle access control and security

  • Impact tested to IWA 14-1: 7.2t at 50mph

  • Bi-directional opening with right or left hand hinging

  • Anti-tamper locking mechanism resists attack by hand and battery tools

  • Lightweight design for easier installation

  • Suitable for remote or out-of-hours security

  • Can be automated with compatible actuators

Applications

  • Perimeter security for critical infrastructure

  • Remote sites with restricted power supply

  • Access points requiring occasional vehicle entry

  • Out-of-hours site security

  • Locations needing hostile vehicle mitigation

Dimensions

Maximum width 4500mm

Standard height 2400mm

Variable height up to 3000mm

Typical foundation depth 600mm

Materials

Made from fully welded steel sections with steel impact boom

Finish

Shotblasted, hot zinc sprayed (galvanised), primed, polyurethane paint topcoat

Options and variations

Manual or automated operation

Right or left hand hinging

Performance

IWA 14-1 tested: 7.2t at 50mph (80kph)

Anti-tamper locking mechanism

Installation

Requires typical foundation depth of 600mm

Accreditations

IWA 14-1 impact tested

Secured by Design

BRE Global
