Ground reinforcement grid for gravel stabilisation

Contain: The honeycomb of cells locks the gravel in position, preventing it being scattered beyond where it has been laid.

Access: The cells and built-in geomembrane stabilise and support gravel, reducing rutting, dipping and pooling. This allows easy movement across gravel surfaces for pedestrians, prams, wheelchairs, wheelbarrows and bikes. ACO GravelGuard also provides a solid base for garden furniture on gravel seating areas and under garden buildings and hot tubs.

Permeable: The open structure of the cells and the permeable geotextile allow rainwater to pass through to the absorbent soil below, replenishing groundwater and reducing rainwater runoff into the sewerage system.

Applications

  • Paths

  • Patios

  • Cycleways

  • Parking spaces

  • Base for garden furniture, buildings and hot tubs

  • Features

  • Both tiles manufactured from polypropylene, with GravelGuard Grey Eco tile (281095) manufactured from 100% recycled polypropylene

  • Cells 47mm diameter and 30mm deep accommodates 10-14mm gravel, stabilising and containing gravel surfaces

  • Cells and permeable geotextile allow rainwater to permeate into soil beneath

  • Geotextile securely bonded to tile, overlaps with adjoining tile and is non-woven so cuts easily

  • Light weight of tiles (3kg) allows easy handling, yet large tile size (1176 x 1535mm) allow quicker installation

  • 24 pegging points per tile for use with ACO 180mm nails, allowing sloped installations of up to 1:12 when pegged

Benefits

  • Tiles are lightweight and supplied folded in half, allowing for easy transport and installation

  • Tiles easily cut to shape for irregular edging

  • Suitable for sloped installations up to 1:12 when pegged

  • Geotextile prevents gravel from sinking into laying course beneath and limits weed growth

  • Combine with ACO BorderGuard where installation adjoins flowerbed or lawn

  • Provides a suitable ground surface for access to buildings in accordance with Building Regulations Part M in England and Wales and Building Standards Section 4 in Scotland

  • Coverage: 5.6 mats per 10m², 17 tiles per pallet, pallet covers 30.68m²

Product options

The ACO GravelGuard Grey Eco tile (281095) has the same features as the GravelGuard White (281093), but is made from 100% recycled polypropylene and is distinguished from the latter by its off-white greyish colour.

The Grey Eco tile is certified by Blue Angel, a German certification scheme for environmentally friendly products. The recycled polypropylene is manufactured from consumer waste plastic. This keeps plastic out of landfill, requires less energy to manufacture than if from raw petroleum and supports a circular economy. For more details of Blue Angel, click here.

NOTE: The GravelGuard Grey Eco tile appears darker in photos due to shadowing, but is nearer to off-white when viewed in person.

ravelGuard tiles speeds up installation. Thanks to this membrane it is difficult for weeds to take root in the gravel. The result is a permanently beautiful and very easy to maintain surface.
