Products Standard headwalls
Material Concrete
Number of segments One piece
Backwall height (mm) 1100-2050mm
Max. pipe diameter (mm) 450 / 500
Weight (kg) 1150 - 1650




A one-piece reinforced concrete headwall to suit plastic or clayware pipes up to 500mm I.D. or PCC pipes up to 450mm I.D.

  • Available with three standard backwall heights, 1.1m, 1.5m and 2m
  • Lifting points cast in to each wingwall for safe handling using Althon lifting clutches
  • Stainless steel sockets provided for the attachment of gratings and special brackets are available for use with the anchorage system
  • Toe extension pieces available for the H6C Headwall giving an overall toe depth of 710mm or 1015mm from the splashplate


A one-piece reinforced concrete headwall to suit plastic or clayware pipes up to 500mm I.D. or PCC pipes up to 450mm I.D.

  • Available with three standard backwall heights, 1.1m, 1.5m and 2m
  • Lifting points cast in to each wingwall for safe handling using Althon lifting clutches
  • Stainless steel sockets provided for the attachment of gratings and special brackets are available for use with the anchorage system
  • Toe extension pieces available for the H6C Headwall giving an overall toe depth of 710mm or 1015mm from the splashplate
