Sliding Gates are suitable for applications where there is restricted space, the ground isn't level, or where a substantial single gate would provide the highest levels of security.

Smooth and virtually silent in operation, the gates are supported on a special carriage so that a single leaf is able to span widths of up to 15m over track, road, rail or water.

Gate panels are constructed to the same exacting standards as Jacksons fencing and are mounted on a substantial bottom rail of formed steel with square section steel support posts.

Key features

  • Safety photocells

  • Safety edges class 3

  • Manual release

  • Flashing warning light

  • IP rated lockable cabinet

  • Suitable for up to 15m single leaf opening

  • Speed of operation up to 400mm per second

  • Options include partial opening facility, and powder coated cabinets

  • Supplied fully CE accredited, conforms to the Machinery Directive 2006/46/EC

Finishes

  • Galvanised to BS EN 1461 as standard

  • Galvanised and powder coated to BS EN 13438 in one of out standard colours (extra cost)

  • Powder coated to any other BS and RAL colour (special order)

Heavy Duty Sliding Gate (Gates up to 8m wide) 100% duty cycle 160mm/sec



Max Operations (1hr)

Max Operation (24hrs)

 4m

 36

500

 5m

28

500

 6m

27

500

 7m

20

480

 8m

18

430

Heavy Duty Sliding Gate (Gates up to 10m wide) 100% duty cycle 340mm/sec



Max Operations (1hr)

Max Operation (24hrs)

 4m

 102

1200

 5m

83

1200

 6m

70

1200

 7m

60

1200

 8m

52

1200

 9m

 46

 1100

 10m

 42

 1000

Heavy Duty Sliding Gate (Gates up to 15m wide) 100% duty cycle 220mm/sec



Max Operations (1hr)

Max Operation (24hrs)

 10.5m

 26

620

 11m

25

600

 11.5m

23

550

 12m

22

525

12.5m

21

500

 13m

20

480

 13.5m

19

450

 14m

18

430

14.5m

17

400

 15m

16

380
