Hy-Tex Gabion Baskets are heavy-duty wire mesh containers made from galvanised steel for retaining walls, erosion control, landscaping, and civil engineering. Supplied flat packed and unfilled, these baskets are available in 3mm or 4mm wire thickness and a range of sizes.

  • Heavy-duty wire mesh containers for stone, rock, or recycled fill
  • Galvanised to EN 10244-2 for corrosion resistance
  • Mesh aperture 76.2 x 76.2mm
  • Easy installation and low maintenance
  • Supports natural drainage and environmental sustainability
  • Customisable fill material and size

Applications

  • Retaining walls
  • Erosion control
  • Landscaping
  • Slope stabilisation
  • Riverbank protection
  • Boundary walls

Dimensions

0.30 x 0.30 x 0.30m

0.50 x 0.50 x 0.50m

1.00 x 1.00 x 0.75m

1.00 x 1.00 x 1.00m

1.00 x 1.00 x 0.50m

1.00 x 0.50 x 0.50m

1.50 x 1.00 x 1.00m

1.50 x 0.50 x 0.50m

1.50 x 1.00 x 0.50m

2.00 x 1.00 x 1.00m

2.00 x 1.00 x 0.50m

2.00 x 0.50 x 0.50m

2.00 x 1.00 x 0.225m

2.00 x 1.00 x 0.30m

Materials

Galvanised steel wire

Finish

Galvanised to EN 10244-2

Options and variations

Wire thickness: 3mm or 4mm

Multiple basket sizes

Performance

Tensile strength: 600–800N/mm² (EN 10218-2 1996)

Excellent drainage

Installation

Supplied flat packed and unfilled

Easy to assemble

Sustainability

Can be filled with recycled materials
