Play unit Lilie is a compact outdoor play structure made from pressure-impregnated softwood and high-pressure laminate, designed for young children from 1 year. Includes climbing ramp, belly board, gate backdrop, staircase, platform, wobbly head, and galvanised steel post bases. Suitable for small spaces and early years settings.

  • Compact play structure for early years outdoor environments

  • Made from pressure-impregnated softwood and high-pressure laminate for durability

  • Includes multiple play elements such as climbing ramp and wobbly head

  • Low freefall height of 40 cm for enhanced safety

  • Minimal installation space required (5.01 x 4.46 x 2.20 m)

  • Galvanised steel post bases for stability

  • Suitable for installation on lawn surfaces

Technical specifications

Material

softwood pressure-impregnated

Minimal space

5,01x4,46x2,20 m

Fall protection netto

7,5 m²

Freefall height

40 cm

Biggest part

Ø 12x180 cm

Heaviest part

23 kg

Foundation level

ET 400

Foundation

6x CF or 3x PFs + 3x PFr

Soil quality

at least lawn

Catalogue index

minimondo Play unit minimondo Lilie

Applications

  • Nursery and preschool outdoor play areas

  • Public playgrounds

  • School playgrounds

  • Community parks

  • Residential developments

Dimensions

Minimum space 5.01 x 4.46 x 2.20 m

Biggest part diameter 12 x 180 cm

Heaviest part 23 kg

Performance

Freefall height 40 cm

Impact protection area 7.5 m²

Materials

Pressure-impregnated softwood

High-pressure laminate (HPL)

Galvanised steel

Installation

Assembly by 1 person in 1.5 hours

Requires 6x CF or 3x PFs + 3x PFr foundations

Suitable for installation on lawn

Sustainability

CO2 emissions 281.6 kg

32% renewable raw materials

14% recycled material

Accreditations

Certificate Z2_010651_0538_Rev00
