PUPS04 service unit - outdoor stainless steel retractable power supply

Retractable power tower, model PUPS04 for the distribution of energy and other services, is for use in HGV areas. Total power 63 amps single- or 3-phase incoming supply. Can be used to supply electricity, water, gas and telephone. Raised by turning handle or with manual lifting.

Units are manufactured in stainless steel AISI304 and have an epoxy-polyester powder finish. Tops are available in stainless steel or cast iron.

The adaptability of pop up power sockets makes them suitable for all outdoor environments. The "Pop Up" feature of the units improves the quality and safety of the surrounding area.

Mechanical specifications

Retractable power tower, model PUPS04 for the distribution of energy and other services, made of press-bent AISI304 stainless steel painted RAL 1021 with two sides available for mounting electrical equipment. Manual lifting by its special hooked-key up to its lock position.Complete with RBK concrete box with the following external dimensions 490x490xh740mm.

Technical details

Structure

• RBK concrete box • Structure: AISI304 stainless steel • Structure: AISI316L stainless steel (only on demand)

Connection system

• Connection to 3 metre (standard) H07RN-F cable tail from unit to be connected to incoming supply by underground polymer joint (torpedo joint)

Electrical specification

Electrical equipment containment box with IP 66 protection IEC 60 529 and CE70-1 double insulation in thermoplastic material free of halogen self-extinguishing halogen, painted grey RAL 7035 resistant to abnormal heat and fire up to 650 ° (incandescent wire test according to IEC 60 695-2 -1). Elastomer sealing gaskets for dimensional stability in continuous operation from -20 ° to + 85 °. Resistance to chemical agents (water, saline solutions, acids, bases and oils) and atmospheric agents. Reference standards: CEI 23-48 and IEC 60 670. This system is suitable for manufacturing equipment and for places with a higher risk of fire (IEC 64-8 / 7).

• Voltage 230V/400V • Frequency from 50hz to 60hz • Standard protection of the sockets IP67 • Regulation EN 60947-1 and EN 61439
